DISTINCTIVE OUTDOOR LIVING SPACES THAT START WITH A STRONG FOUNDATION
OUR CONSTRUCTION PROCESS IS WHAT SETS US APART FROM OTHER LANDSCAPE CONTRACTORS IN THE
TWIN CITIES AREA. WE’RE CONSTANTLY LEARNING NEW, INNOVATIVE CONSTRUCTION TECHNIQUES
AND BUILD EACH PROJECT WITH THE GOAL TO LAST A LIFETIME!
The “standard” paver construction process:
Excavate 12″ of soil
Fill it full of crushed 3/4″ minus limestone, and pack it really hard
Do a final grade with mason sand
Put down the pavers and compact
Pack up the truck and move on to the next one
“THE WAY WE’VE ALWAYS DONE IT” DOESN’T CUT IT ANYMORE…
HERE’S OUR UNIQUE CONSTRUCTION PROCESS
We don’t just excavate to an arbitrary 12″ depth, we excavate based on soil conditions. During traditional aggregate base construction, we excavate to remove “loam” soil, as it is unpredictable in both bearing ability and compaction. As well, loam soil contains organic material that can decompose over time, leaving voids beneath the base. As a rule of thumb, in the St. Croix River Valley, loam soil is approximately 12″ deep. This is where the standard “12-inch base” comes from, but is not ALWAYS the case when excavating for interlocking pavements.
The base is excavated using a laser level to reflect the finished grade of the interlock pavers. This ensures your landscape will react uniformly during freeze/thaw cycles.
Sometimes, if you’re landscaping in WI/MN, once the loam soil is removed, clay can be present. At this stage, we perform a soil acidity test and/or various consistency tests to better understand the subgrade conditions.
From there, we use that data to reinforce the subgrade. Employing hydrated lime or incorporating clear stone into the soil to increase bearing ability. This also determines what type of aggregate we use in the base construction process.
The entire excavation (sides & bottom) is wrapped in woven geotextile fabric. This is shingled away from the house, with overlap based on subgrade conditions. Excess geotextile is left higher than the sides of the excavation, which will be trimmed later. This ensures no soil is able to mix with the aggregate. It’s not “landscaping fabric” for weed control.
If soil infiltration rates will allow, we prefer to use 3/4″ Washed Limestone in our landscapes. Its many advantages include not holding moisture, making it more predictable during freeze/thaw cycles. It compacts more easily than the traditional “3/4 minus” Crushed Gravel, helping to speed along the interlocking paver construction process.
After backfilling and compacting the aggregate to within ~6″ of the final grade, we install an exciting innovation in the landscape industry called “Triaxial Geogrid”.
We then fill the remainder with the same aggregate until we reach the tolerated heights for the setting bed and pavers.
Next up is the setting bed: if Clear Stone was used, a smaller 3/8″ clear limestone is used as the setting bed. This allows water to permeate and fine-tunes the grade for the paver installation. If Crushed Stone is used, a Washed Concrete Sand setting bed is installed over a further layer of geotextile fabric; this allows water to permeate away from the pavers and travel over the heavily compacted Crushed Stone base.
Water allowed to sit on the bottom of the interlock pavers will degrade their integrity over time. For this reason, We Do NOT Use Stone Dust. Stone Dust is the waste collected during the manufacturing of structural aggregates such as concrete. It can be compacted to be hard like cement but will trap water between itself and the paver.
There have been so many advancements in landscaping and geotechnical engineering technology that, “the way we’ve always done it,” no longer cuts it. The Twin Cities Metro experiences some of the most frequent freeze/thaw cycles and most extreme temperature differences of all the capital cities in the world. We’re forced to be more innovative in our landscape construction than in any other market. Interlocking Concrete Pavement, built to ICPI standards has an average life expectancy of 30-100 years.
Commonly mistaken for “weed cloth” but actually has nothing to do with weed control at all!
Used to separate and stabilize dissimilar soils and aggregates, its main use is to prevent subgrade soil from mixing with the gravel above.
Most of the time when interlock installations fail, it happens from the underneath and the sides, as the gravel base migrates into the surrounding soil or vice versa.
TENSAR TRIAXIAL GEOGRID
Our secret weapon for a base that lasts!
- Originally innovated for railroad construction, geogrid structurally stabilizes aggregate bases and retaining walls.
- It is becoming more and more commonly used within the landscaping industry, however, not all companies have gotten on board. We’ve stayed ahead of the curve and had several years of experience installing this crucial new product!
If you have a backyard with very tight access this is the product for you!
Synthetic base replicates the insulating value and weight distribution of a traditional interlock paver aggregate base.
Lots of backyards in the Twin Cities suburbs can have very tight access. Gatorbase allows us to efficiently build a patio for a fraction of the cost when machine access is limited. Less excavation, less backfill, same beautiful interlock patio!
POLYMERIC JOINT STABILIZATION
- PaverMate Z3 polymeric sand, by SRW Products, is simply the best on the market. It becomes almost as rigid as the pavers themselves, and is rain safe within 10 minutes! No worries about high heels getting stuck in larger joints with certain interlock paver types!
- Zero Haze: Portland-free formula cleanly sweeps to reduce any material left on the paver surface.
- Zero Dust: Polymers bind to each other and the sand particles creating anti-dusting results…which means a cleaner and safer jobsite!
- Zero Problems: Provides protection against unexpected rain events – rain safe in 10 minutes.
The best part about GOOD polymeric sand? NO WEEDS! When properly installed, polymeric sand makes your interlock virtually maintenance-free!
Our paver manufacturer offers a LIFETIME WARRANTY on most of their products. We’ve chosen the best landscaping products, to build the best landscapes.
Each paver and slab has pure color pigments and fine aggregates that are blended on the surface, providing vibrant, rich, and long-lasting colors.
We only use products that are high-quality, and long-lasting without compromising design or aesthetics.
Our paver craftsmanship is where the true difference becomes apparent.
- Genesis Face-Mix Technology provides more than surface beauty. Genesis ensures long-lasting color, superior strength and resistance, and unique surface textures. Our pavers and slabs repel stains and withstand everyday wear and tear. Ask about our Genesis Face-Mix Technology to learn more!
STEPS & RETAINING WALLS
Like our pavers, all the wall block materials we use are top of the line. We choose them based on their structural engineering, practicality and ultimately what style best matches your home.
When structures are being built beside your home’s foundation, we don’t use the foundation as retention. Our step and raised structures are always built independently from the house, to avoid placing weight load on your home, and to make the structure even stronger.
We tie everything together with Biaxial Geogrid! If any part of the raised landscape wants to move or settle in any direction, it must pull the entire step with it!
Retaining walls are always backfilled with drainage stone and reinforced with Biaxial Geogrid.
CONCRETE OVERLAYS (POOL DECKS & STEPS)
- Stamped concrete pool decks and stoops are high-maintenance surfaces that need to be sealed regularly, this sealer can be slick when wet creating safety concerns.
- Paver overlays are 2-3 times denser than concrete and do not need to be sealed.
- Most steel framed pools in the St. Croix Valley are excavated with a 24″ “over-dig” so the pool walls can be anchored in with concrete. This method creates a unique situation where traditional paver base compaction isn’t possible, hence the need for a concrete “sub-deck” foundation for the pavers.
- Pavers are a great option for pool decks because they are durable; chlorine and salt resistant, and can provide the look of natural stone. Pavers also provide good traction and are comfortable underfoot, because the joints take on moisture that helps cool the surface.
- Covering your existing concrete porch with pavers is a great way to complement the surrounding landscaping.
LANDMARKS & FEATURES
MAKE THE MOST OF YOUR ENTIRE PROPERTY BY ADDING UNIQUE OUTDOOR FEATURES TO COMPLIMENT YOUR LANDSCAPE & CREATE A COMPLETE OUTDOOR LIVING SPACE.
Interlock pavers are our specialty, but there’s so much more that can be done with your yard. Adding focal points and landmarks turns your backyard into YOUR living space!
You may define your yard with a statuesque pergola or add a unique large boulder. Relax in an in-ground pool or enjoy the tranquility of a natural water feature. Illuminate your investment by adding landscape lighting and keep warm on chilly nights with a fire feature. Love to cook? An outdoor kitchen could be a great match. Cover up your existing concrete porch to create a cohesive landscape. While we’re building, have you thought about drainage solutions? We can get rid of unsightly and annoying eavestrough extensions.
Whatever you love to do in your yard, we have a special feature for you!
Natural gas outdoor fire pits are a fantastic way to extend the season of enjoyment with your outdoor living space! Fire pits light up the night and provide warmth while you spend time with friends and family into autumn.
Learn more >
Adding a splash of water to your outdoor living space brings a conversation piece that will provide the therapeutic sound of flowing water and attract butterflies and birds to your garden.
Learn more >
Landscape lighting can enhance the look of the outdoor space and create an ambiance to enjoy throughout the evening. Ambient lighting also adds safety and security to your home.
Learn more >
Whether you’re relaxing under a pergola or on a deck, we can build you a custom addition built using the highest quality materials.
Learn more >
Gather your friends and family and make memories with your very own in-ground pool. Lounge while the kids play, and enjoy the benefits of health and relaxation. We work with the best pool installers in the Twin Cities Metro.
Learn more >
The comfort of your kitchen, the beauty of the outdoors. Options are endless when it comes to building an outdoor kitchen – from integrated BBQs to fridges, sinks, and storage, we can do it all!
Learn more >
A decorative boulder can create a major focal point and offer distinction in water features and gardens. Available in a variety of materials and sizes.
Learn more >
We use a large variety of interesting and unique trees, shrubs, evergreens, and perennials. We are as passionate about your softscape as we are about your hardscape!
Learn more >
WHAT ARE YOU WAITING FOR?
NOW BOOKING FOR SUMMER/FALL 2021
We’d love to help you with your next landscaping project, contact us today about setting up a consultation. Our construction schedule fills up fast, so don’t wait!
